Industrial Side Entry Agitator
Side Entry Agitators for great performance
Heavy Duty Side Entry Agitators are highly suitable for maintaining and mixing products in medium and large volume vessels.
Industrial Side Entry Agitator for Continuous Tank Circulation and Sedimentation Control
The Industrial Side Entry Agitator is a heavy-duty side mounted tank mixer engineered for efficient circulation, homogenization, and sedimentation control in large industrial storage tanks. Designed for energy-efficient operation, it delivers consistent blending performance while minimizing structural and installation costs.
Discover how Industrial Side Entry Agitator can enhance your production line.
Engineering Design & Mechanical Features
This tank circulation system is specifically designed for slender storage tanks up to 17 meters in height.
Mechanical Highlights:
- Worm gear reducer for compact, cost-effective torque transmission
- Hollow shaft gearbox connection for stable mechanical alignment
- Direct shaft coupling secured with head screw for low-maintenance reliability
- Internal mechanical sealing system (standard graphite/SS configuration)
The modular design supports simplified installation in tanks with limited structural load capacity.
Available Configuration Options
To meet various industrial requirements, multiple configuration options are available:
For Viscous or Sugary Products
- Hard-faced mechanical sealing surfaces
- Improved abrasion resistance
For Hygienic Applications
- Sterilizable sealing system
- Protected spring design to prevent contamination buildup
For Hazardous Environments
- Enhanced chemical-resistant sealing materials
- Improved process safety performance
Flanged Lantern Version
- Cartridge-type mechanical seal
- Simplified seal replacement
- Increased operational uptime
What is a Industrial Side Entry Agitator?
An Industrial Side Entry Agitator is a horizontally mounted mixing system installed on the side wall of a storage or process tank. Unlike top-entry mixers, this configuration preserves roof space while generating powerful axial flow across the tank diameter. Its lateral installation enables efficient large-volume circulation without requiring heavy structural reinforcement.
Industrial Side Entry Agitator Advantages
An Industrial Side Entry Agitator provides efficient and cost-effective mixing for large storage tanks across oil & gas, chemical, food, and industrial applications. Its lateral mounting design ensures strong fluid circulation, prevents sedimentation, and reduces energy consumption compared to conventional top-entry mixers.
Key Advantages
- Optimized mixing performance in large-diameter tanks
- Reduced sludge and stratification
- Lower installation and structural costs
- Easy maintenance and accessibility
- Reliable 24/7 industrial operation
How Does a Industrial Side Entry Agitator Work?
An Industrial Side Entry Agitator operates by generating controlled horizontal fluid circulation inside large storage or process tanks. Mounted on the side wall of the tank, the unit uses a motor and gearbox assembly to transmit torque to a rotating shaft and impeller positioned inside the vessel.
When activated, the impeller creates a strong axial flow pattern that moves liquid across the tank diameter. This continuous circulation prevents sedimentation, reduces stratification, and maintains uniform product composition.
The gearbox reduces motor speed while increasing torque, enabling stable low-speed operation suitable for bulk liquid storage, crude oil blending, chemical processing, food production, and wastewater treatment. Depending on tank size and process requirements, multiple units can be installed to optimize internal flow dynamics.
This working principle makes the Industrial Side Entry Agitator a reliable, energy-efficient solution for large-scale industrial tank mixing.
Which Industries Is It Suitable For?
The Industrial Side Entry Agitator is designed for large-scale storage and process tanks where continuous circulation, sedimentation prevention, and product homogenization are critical. Its robust and compact side-mounted design makes it suitable for a wide range of heavy-duty industrial environments.
Main Application Areas
